Raptor 6.8kVa 5500W Electric Start Generator RG5500

Raptor generators are exclusively designed to provide reliable, clean and high-quality electricity with silent operation and long run times. Robustly built, yet light weight, the Ergonomic and compact design makes transportation and manoeuvrability an easy task. Manufactured using the highest quality components, Raptor generators takes portable power to the next level. With features like no other, they are the epitome of quality generators.

• Features
• Robust frame, tubular construction technology
• Advanced overhead valve, 4- stroke engine with recoil starter and anti-vibration mounts
• Quality exhaust system ensures a fireproof and quiet operation
• Useful 12v DC socket outlet ideal for charging batteries
• High quality copper wound alternator
• Safety rated electrical circuit breakers
• Low engine oil safety shutdown
• Corrosion resistance finish gives long life in harsh conditions
• RCD safety switch - A safety switch that protects against a 240-volt electric shock that could cause serious injury and even death
• Weatherproof outlets- IP66 plugs
• Sine wave technology
• Automatic voltage regulator
• Digital VFT meter
• Handle and wheel kit included
• Australian Standard compliance AS/NZS3112:2017
• (Construction & demolition sites, work cover approved)

Specifications:

• Engine: GK420
• Displacement (cc): 420
• RPM: 3600
• Fuel Tank: 25L
• Fuel Gauge: yes
• Starting Method: E-start
• Noise Level: 76dBa (7m)
• Low oil pressure safety shut down: yes
• Run time @ 50% Load (hours): 10
• Run time @ 100% Load (hours): 8
• EPA approved: yes
• Backup battery 9Ah: yes

240 VOLT AC ELECTRICAL

• Voltage: 240v
• Frequency: 50HZ
• Continuous Running Power (Watts): 5000
• Maximum Starting Power (Watts): 5500
• Max. output (KVA): 6.85
• Continuous Running Current (Amps): 20.8
• Voltage Control
• Outlets: 2x 15 A, 1P66
• Overload Circuit Breaker: yes
• RCD Safety Switch: yes
• Digital VFT Meter: yes

12 VOLT DC ELECTRICAL

• Maximum Power (Watts): 100
• Maximum Current (Amps): 8.3

Accessories

• Wheels & Handles yes
• Engine Oil & Spark Plug Tool yes

• Net Weight (kg): 83
• Dimensions (L x W x H mm): 715 x 570 x 585
